TENDA Lều cắm trại O1 CPE đầu nhọn dài 500m

Outdoor 500m Point to Point CPE Access Point AP tent

The O1 2.4GHz Outdoor CPE tent was designed for WISP CPE solutions and remote wireless network solutions for video surveillance and data transmission. The O1 CPE tent has an 8dBi directional antenna to provide efficient means of retrieving and maintaining a stable signal for wireless networks. The product adopts auto-bridging technology, two CPE so that it can be connected to each other automatically to facilitate setting.

Dimension: 190.35x80 x 67.5mm

Ssid Hidden Pole Mount

Frequency: 2.4GHz

300Mbps wireless Link Rate

Antenna:
- Gain Antennas: 8dbi
- Horizontal: 60 Vertical: 30 Antenna Beamwidth

Button: 1xreset Button

Maximum power consumption: 2.6W

Waterproof level: IP65

Poe / LAN,WiFi,LED1,LED2,LED3

Dc or Passive PoE electric power method

Passive power over ethenet via PoE / LAN (+ 4.5pins)
Up to 30 meters.

Input voltage: 9-12V DC

Acceptance sensitivity
- MCS0: - 92dbm.
- MCS7: 72dbm.

Ap / Station / WISP operations mode

Standard & protocol: IEEE 802.11b / g / n

Default settings:
- Default login IP: 192.168.2.1
- Default Login username: Admin
- Default Login password: Admin

Package contents:
1X Outdoor Point to Point O1 CPE
1X Power Adapter
1X PoE Injector
2X Plastic staples
1X Quick installlation Guide
