Camera Lùi Xe Hd 170 + Màn Hình 4.3 "tft Lcd

Specifications:
Material:Plastic

Display size:4.3 inch LCD screen 16:9

LCD Display Resolution:480*272

Camera Image Sensor:Color 1/4 Sensor CCD

TV System:NTSC

Camera Resolution:640(H)×480(V) Pixel

Horizontal Resolution:480TVL

Min Illumination:0.5LUX

LED Quantity:4 pcs

Lens Angle:170°

Night Vision:Yes (not IR night vision)

Night Vision Range:Max 2m / 6.5ft

Automatic White Balance:Yes

Automatic Backlight Compensation:Yes

S/N Ratio:≥48dB

Operating Power Display: DC 12-24V; Camera: DC 12V

Power:2W

Operating Temperature Display: 0~80°C, camera: -20°C~ 80°C, RH95% Max

Storage Temperature:-30°C ~ 70°C, RH95% Max

Video Cable Length:6m / 20ft

Power Cable Length:1m / 3.3ft

Waterproof rated: IP67

Display Size:12.5x9x6cm / 4.9x3.5x2.4"

Camera Bracket Size:4x2.2cm / 1.6x0.9" (L*W)

Camera Size: 2.3x2.3x2.5cm / 0.9x0.9x1" (L*W*H)

Features:
Shock-resistant.

Dual AV input.

High-quality CCD chip, intelligent HD processing.

Nano glass lens, clearer HD lens picture.

Large 170 degree angle visual range, fulfill all demands of driving forward or backing up.

The camera support night vision design, 480TV line and 4 LED beads offers you a brighter viewing angle in dark environment and provides big improvement of reversing cars, which is perfect for avoiding car crashes while driving in the dark.

This kit can be installed on all 12-24V cars.

Package Included:
1x LCD Display

1x Car Rear View Camera

1x 6m Extension Video Cable

2x 1m Power Cable

2x Screws

1x 3m Sticker

1x English User Manual

1x Package Box

Notes:
The colors may be a little difference for the different monitor display.

Please allow minor deviation due to manual measurement.
