Bộ Chuyển Đổi Ubiquiti Poe-50-60w Poe 50v Dc 1.2a 60w Chính Hãng Ori

Poe-50-60w is a ubiquiti networks 50vdc 1.2a replacement gigabit poe adapter. Combined with toughcable, you can effectively protect against any esd attack



Product specifications.

! Dimensions: 101x60 x 33mm (3.98x2.36x1.30 ")

! Weight: 192g (6.77oz)

! Output voltage: 50vdc @ 1.2a

! Lan port gigabit: Yes

! Voltage input: 90-260vac @ 47-63hz

! Current input:

1.3a @ 120vac.

0.75a @ 230vac

! Inrush current:

< 100a peak @ 120vac

< 200a peak @ 230vac

! Efficacy: 85 +%

! Output ripple: 1% max.

! Switching frequency: 65khz

! Line regulation:1%

! Load regulation:3%.

! 4-pair powering: Pins 1,2,4,5 (+) and pins 3,6,7,8 (-)

! Operating temperature: 0 to 40?C (32 to 104?- f)

! Temperature storage: - 30 to 70?C (- 22 to 158?- f)

! Operating humidity: 35 to 95% non-condensing

! Ac connector iec-320 c6

! Rj45 shielded socket in / poe data

! Surge protection: Difference and common mode

! 11v data, 60v power

! - max. Surge rechargeable: 1500a (8 / 20us) power

! Peak pulse current: 36a (10 / 1000us)

! Shunt capacitance: < 5pf data

! Response time: < 1ns
